Fire Sealing Electrical Box with Putty pad
Description:
Putty Pad is a moldable fire-rated putty material with intumescent properties. When exposed to flames or high temperature will prevent the spread of flames, smoke, and toxic gases through openings in fire Rated walls and partitions. INCA Putty Pad is designed to protect electrical boxes or other penetrants with up to 2-hour fire resistance and is easy to install, reuse or retrofit.
Applications:
Putty Pad is used to seal around metal outlet boxes to increase fire resistance and sound insulation.
- Color: Black
- Appearance: Solid, moldable
- Thickness: 3/16”(5mm)
- Expansion rate: 5~10 times
- Curing time: None
- Surface Burning Characteristic (ASTM E84)
- Flame spread: 0; Smoke development: 0
- Sound Transmission Class(ASTM E90):
- STC Rating 63 (Per construction type)
Properties:
- Applied by hand, reuse and is re-penetrable
- Wall opening protective tested up to 2 hours in accordance with UL 1479(category CLIV)
- Non-halogenated, Asbestos free, Low VOC
- Provides draft and smoke seal
- Highly intumescent when exposed to fire
- Excellent sound insulation properties
